High-Precision UV Printing with Advanced Vision Positioning

The Audley 9060 Vision Positioning UV Printer is a cutting-edge flatbed UV printer designed for high-accuracy, multi-material printing. Featuring 3 Epson I3200-U1 print heads, this printer delivers stunning image quality, fast production speeds, and durable UV-cured prints on a variety of rigid and flexible substrates. The built-in visual positioning technology enhances precision, making it the ideal solution for industrial, commercial, and custom product printing.

With a 900mm print width and support for materials up to 150mm thick, the 9060 Vision Positioning UV Printer is perfect for businesses looking to expand their product offerings with customized signage, promotional items, product branding, and specialty printing applications.

Key Features of the Audley 9060 Vision Positioning UV Printer

• Advanced Visual Positioning Technology – Increases print alignment accuracy, ensuring sharp, high-resolution designs on a variety of substrates.
• 3 Epson I3200-U1 Print Heads – Provides consistent ink flow and exceptional detail for vivid, full-color prints.
• High-Speed Printing Options:
  • 4PASS: 8㎡/h for fast production
  • 8PASS: 4㎡/h for balanced speed and quality
  • 12PASS: 3.5㎡/h for ultra-fine detail and color accuracy
• Multi-Material Compatibility: Print on metal, leather, wood, plastic, glass, ceramic, and more.
• Suction Platform for Stability – Keeps substrates in place for precise and uniform printing results.
• Anti-Collision System – Prevents damage to printheads by detecting obstacles.
• Continuous Ink Supply System – Ensures uninterrupted printing with optimized ink flow.
• UV LED Curing System – Utilizes 3 LED lamps with water cooling for instant drying and long-lasting prints.
• Professional RIP Software: Photoprint for advanced color management and image processing.

Understanding Vision Positioning in the Audley 9060 UV Printer

What is Vision Positioning Technology?

Vision positioning technology in the Audley 9060 Vision Positioning UV Printer is an advanced image alignment and detection system that enhances printing accuracy and precision. It uses built-in cameras and software algorithms to detect the exact position, shape, and orientation of objects on the printing bed, ensuring that prints are applied perfectly aligned every time.

This technology is particularly useful for printing on irregularly shaped, pre-cut, or pre-printed items, where exact positioning is required to avoid misalignment and ink waste.

How Does Vision Positioning Work?

The vision positioning system operates in several key steps:

1. Object Recognition and Registration

• The printer’s built-in camera system scans the surface of the material placed on the print bed.
• The system detects the edges, shape, and orientation of the object using high-precision optical sensors.
• The software registers the exact position of the object, even if it is slightly misplaced or rotated.

2. Automatic Print Alignment

• Once the object’s position is mapped, the vision system adjusts the print layout accordingly, ensuring that the design is centered, straight, and perfectly positioned on the substrate.
• Even if the material was not placed in a perfect position, the software realigns the print design automatically, preventing printing errors.

3. Real-Time Corrections and Adjustments

• The system continuously tracks the printing position throughout the process, making real-time micro-adjustments as needed.
• This feature is especially useful for pre-cut objects like phone cases, promotional products, or pre-printed surfaces, where even a slight misalignment could ruin the final product.

4. High-Precision Printing on Multiple Substrates

• Unlike traditional UV printers that rely solely on manual alignment, the vision positioning system allows for:
  • Accurate multi-layer printing (such as white + color + varnish layers) without misalignment.
  • Printing on irregularly shaped objects with different sizes or cut-out sections.
  • Batch processing of multiple items with automatic detection of each piece’s position.

Why is Vision Positioning Important?

• Reduces Printing Errors & Material Waste – Ensures that prints are always perfectly aligned, even if objects are not placed precisely.
• Enhances Productivity – Faster setup time and less manual adjustment mean higher efficiency in mass production environments.
• Enables Complex & Multi-Layer Printing – Ideal for 3D texturing, spot varnish effects, and white ink layering on precise locations.
• Supports Non-Standard Print Jobs – Perfect for custom-shaped materials, promotional items, and pre-printed substrates.

Warranty

·       1-Year Full Coverage Warranty (Excluding Print Heads): Protects all major machine components (excluding print heads), giving you peace of mind and ensuring minimal downtime for your production.

Software

·       Photoprint Software ($499 Value): Comes bundled with Photoprint software at no extra cost, so you can start producing vibrant, precise prints from day one. Photoprint is trusted for its advanced color management and seamless compatibility.

Support

·       18-Hour U.S.-Based Online Support: Our knowledgeable support team is ready nearly around the clock to assist you, minimizing downtime and keeping production on track. One Complimentary On-Site Repair: Within the warranty period, we offer a one-time no-cost on-site repair to address any eligible issues, maximizing machine uptime for your business.

Installation & Training Options

·       Free Online Setup Resources: Access a library of video tutorials and step-by-step guides designed to make setup easy, even for first-time users.

·       On-Site Installation & Training ($500): For a one-time fee, we provide comprehensive on-site setup and personalized training to ensure your team can operate the printer confidently and efficiently from day one.

Technical Specifications

Expanding Printing Possibilities with Oversized and Specialty Products

The Audley 9060 Vision Positioning UV Printer is not limited to standard signage and promotional items. With its 900mm print width and advanced positioning system, it allows businesses to print on larger and more complex products with precision and durability. Some of its unique applications include:

• Custom Gaming Desks & Large Mouse Pads – Print vibrant, full-width designs on gaming surfaces and oversized desk mats.
• Branded Commercial Appliances & Industrial Equipment Panels – Directly apply company logos, labels, and safety instructions onto metal and plastic casings.
• Decorative Glass & Acrylic Panels – Create full-scale custom wall art, privacy screens, and branded glass displays.
• Custom Luggage & Hard-Shell Cases – Print high-quality, scratch-resistant graphics on travel gear.
• Skateboard Decks & Sports Equipment – Add high-resolution, full-color artwork onto skateboards, helmets, and protective gear.
• Large Corporate Plaques & Award Displays – Print detailed graphics and text on oversized trophies, plaques, and recognition awards.
• Promotional Event Materials & Custom Packaging – Create limited edition packaging, event signage, and promotional gifts with full-color UV prints.

With its industrial-grade construction, high-precision printing, and versatile material compatibility, the Audley 9060 Vision Positioning UV Printer is an essential machine for businesses looking to expand into high-margin, specialty printing markets.

Why Choose the Audley 9060 Vision Positioning UV Printer?

• High-Speed, High-Accuracy UV Printing – Built for efficient, large-scale production with advanced visual positioning.
• Multi-Material & Large Format Capabilities – Supports oversized products, thick materials, and various surfaces.
• Low Maintenance & Long-Lasting Performance – Equipped with a reliable ink system, anti-collision sensors, and precision-guided printing technology.
• Industry-Leading Print Quality – Produces sharp, durable, and scratch-resistant prints with vivid color reproduction.

Upgrade your UV printing business with the Audley 9060 Vision Positioning UV Printer – engineered for speed, precision, and limitless creativity.
